The HAGANE Body is a metal reel body with high rigidity. The body rigidity and impact resistance virtually eliminates body flexing on the reel while fighting fish. The result transforms the angler's actions directly into cranking power, increasing efficiency through strength.

Shimano's exclusive manufacturing technology further advances MicroModule Gear II with a state-of-the-art gear-tooth surface design. The surfaces of the drive gear and pinion gear have been analyzed and updated from the ground up in Shimano’s pursuit of perfection to further improve the smooth gear feeling and reducing sound.

X-Ship provides improved gear durability. By supporting the pinion gear on both ends with bearings, the pinion gear maintains precise alignment with the drive gear. This allows the gears to stay in the same position under the heaviest loads. The added benefit of X-Ship technology is that friction between the spool shaft and gear are eliminated. This further benefits anglers with enhanced casting performance and casting distance of lighter lures.

The Long Stroke Spool has a longer stroke compared to conventional spool designs. This ultimately produces a smoother line lay during retrieval and translates into increased casting distance for anglers.

S A-RB bearings are put through the same process as Shimano’s A-RB bearings but feature shields on both sides of the bearings. These shields reduce the possibility of salt or sand inhibiting rotation of the bearing.

This two-speed oscillation system layers the line onto the spool in a precise crisscross pattern that reduces line-to-line friction for longer casts. Reels with Aero Wrap II technology utilize a patented worm gear design to move the spool upward quickly and downward slowly to wind the line in a precise pattern, reducing friction and giving anglers smoother and longer casting ability.

G-Free Body technology has been developed to shift the reel's center of gravity closer to the rod. By moving the center of gravity closer to the angler’s hand, the G-Free Body helps to reduce fatigue and enhance casting comfort.

X-Protect provides high-level water resistance without sacrificing light gear and rotor rotation. By combining Shimano’s water-repellent coating with a water-channeling labyrinth construction, X-Protect provides added durability in tough conditions.

With the use of rubber gaskets the drag is sealed against intrusion of the elements such as water and dust.

One-Piece Bail allows the line to travel unimpeded to the line roller. The seamless design reduces friction and decreases the chance of tangles or the line catching on the bail arm.

With amazing strength and durability, the HAGANE Gear is at the very heart of most Shimano reels. Shimano, through the application of state-of-the-art technologies, gives anglers the long-lasting smoothness and pleasure that is felt when anglers first use a reel, over and over again. No cutting work is applied to the teeth of the drive gear during fabrication, instead the entire surface is calculated in minute detail by special 3D-design and then formed by Shimano's cold-forging technology. The result is assured resilience. HAGANE Gear is the fruit of Shimano's inexhaustible pursuit for durability — the strength and power of forged metal continues to represent the fundamental concept of Shimano reels.

Shimano's proprietary EI surface treatment of the spool and body creates corrosion resistance that is more than double compared to conventional surface treatments.

The Cross Carbon Drag material provides a wider range of drag settings compared to traditional drag materials. The Cross Carbon Drag provides the smoothest Shimano drag performance ever while providing anglers with increased durability.

By strengthening the spool support of the main shaft, the play and fluctuation of the spool during drag operation are suppressed. The Rigid Support Drag allows smooth and consistent drag delivery, even under high load.

With the Platinum Service Plan, when submitting your Warranty Registration card points, you will receive coupons for discounts on clean and lubes (from half off to free!) Also included are Priority Shipping labels guaranteeing 48-hour turn around time from Shimano or participating Shimano Authorized Warranty Centers.

The most obvious component of the Propulsion Line Management System is the new Propulsion Spool Lip design. Through tens of thousands of casting tests and computer simulations, Shimano’s new spool lip design provides longer casting distances than a standard spool lip design while also preventing backlashes and wind knots from forming.

SilentDrive technology benefits from a total redesign of all functional parts focused on the drive gear, worm shaft and other parts. The goal: remove unnecessary noise and vibration. In doing so, the overall tolerances are improved to a micron level, ultimately creating an overall quieter and smoother reel operation.

PRODUCT CODE	WEIGHT	POWERPRO LINE CAPACITY	LINE RETRIEVE PER CRANK	GEAR RATIO	BEARINGS	MONO LINE CAPACITY	MAX DRAG	SKU
STL1000FJ	6	10/95, 15/85, 20/65	25	5.1:1	12+1	2/270, 4/140, 6/110	7	STL1000FJ
STL2500HGFJ	7.2	10/150, 15/145, 30/100	35	6.0:1	12+1	6/200, 8/140, 10/120	20	STL2500HGFJ
STL4000XGFJ	9	15/230, 30/180, 50/120	40	6.2:1	12+1	8/240, 10/200, 12/160	24	STL4000XGFJ
STLC3000XGFJ	7.4	10/200, 20/140, 40/105	37	6.4:1	12+1	6/230, 8/170, 10/140	20	STLC3000XGFJ
STLC5000XGFJ	9.2	20/260, 30/235, 40/185	40	6.2:1	12+1	10/240, 12/195, 14/165	24	STLC5000XGFJ
